進線直徑

Single wire diameter

Φ0.6~4.0㎜

Φ1.0~20.0㎜

絞合直徑

Twisted diameter

MAXΦ4.0㎜

MAXΦ4.0㎜

絞   距

Twist pitch range

15~60㎜

15~60㎜

轉   速

Rotating speed

MAX 1200RPM

MAX 100RPM

驅動馬達

Drive motor

5HP Motor+

Frequency adjust speed

7.5HP Motor+

Frequency adjust speed

排線方式

Layout mode

軸排式收線，線材排線過程中無推拉損傷，排幅排距按線材規格設定。

Shaft arrange take-up,no damge ing product process,the size could be established by yourself.

制動方式

Braking method

⑴懸臂主軸：碟式剎車   ⑵收線卷?。弘姶艅x車

⑴ Cantilever spindle: Disc brake ⑵ Take-up and take-up: Electromagnetic brake

放線方式

Pay-off   method

動力放線、雙變頻調速，與主機聯動控制，設定斷線保護功能。

Power pay off, double frequency control, linkage control with the host machine, setting the disconnection protection function.

芯線張力

Core tension

直線滑軌+滑塊重錘式/機械扛桿+滑塊移動式，在線張力檢測上顯示

Linear slide rail + slider heavy hammer type / mechanical carrying rod + slider mobile type, displayed on the online tension detection

包帶張力

Taping tension

收線張力

take-up tension

恒張力電磁剎車輪、自動張力跟蹤，包帶、收線張力從滿盤到空盤保持恒定，無需手動調整。

Constant-tension electromagnetic brake wheel, automatic tension tracking, the tension of the tape and take-up is kept constant from full reel to empty reel, without manual adjustment.

放線線軸

shaft of pay-off

Φ300~500㎜

收線線軸

shaft of take-up

Φ400~500㎜
