回轉速度Rotate speed

MAX.1800RPM

驅動馬達Drive motor

7.5HP Motor+Controlled inverter

單根線徑Diameter of each wire

Φ0.6~1.5㎜

絞   距Twist pitch range

11.00～123.00mm

絞 向Twisting direction

左右絞向可調，“S” or “Z” direction

線盤裝銅量Weight of conductor on reel

300~450㎏

機械尺寸Mechanical Dimensions

L2690×W1480×H1460

機械重量Machine net weight

2200㎏

使用電源Voltage frequency

50HZ/380V

排線裝置Cable device

加強型精密光桿排線器，排輻、排距均可調整

Enhanced polished rod cable arranging device, row spacing and row width can be adjusted at will

收線張力Take-up tension

磁粉離合器控制張力、大小可調節，被拉線不變型。

The magnetic powder clutch controls the tension, the size can be adjusted, and the drawn wire does not change shape.

保護功能Protective function

⑴長度到達設定參數自動停機

The length meter will automatically stop when it reaches the set parameters;

⑵設備內部和外部斷線，自動停機報警The internal and external disconnection of the equipment will automatically stop and alarm;

⑶安全罩打開自動停機

It will stop automatically when the lift is incorrect

⑷升降不正確自動停機

It will stop automatically when the safety cover is opened。

⑸紅色警示燈：故障停機

Red warning light: shutdown due to failure
